U-shaped Stainless Steel Shaftless Spiral Drill Blade Ash, Cement,
Sludge Pipe Spiral Conveyor
Spiral Conveyor Function
Efficient Conveyance: Suitable for horizontal or inclined
conveyance of powdered, granular, and small lumpy materials such as
grains, coal, flour, cement, etc., with high conveyance efficiency.
Versatile Applicability: Can be used in environmental temperatures
ranging from -20 to 50 ℃, with conveyed material temperatures not
exceeding 200 ℃, adapting to various working environments.
Fully Enclosed Design: The fully enclosed structure effectively
prevents the leakage of dust, corrosive, or hazardous substances,
ensuring the safety and hygiene of the working environment.
Spiral Conveyor Application
1.Food Processing: Used for conveying food raw materials such as
grains and flour.
2.Pharmaceuticals: Suitable for conveying pharmaceutical raw
materials such as powdered medicine and granules.
3.Powder and Energy: Used for conveying energy materials such as
coal and fly ash.
4.Petrochemicals: Suitable for conveying petrochemical raw
materials and fertilizers.
5.Mining and Minerals: Used for conveying mineral materials such as
ore and ore powder.
Spiral Conveyor Technical Parameters
| Attribute | Description |
|---|
| Material | U-shaped Stainless Steel |
| Structure Type | Shaftless Spiral Drill Blade |
| Conveyed Materials | Powdered, Granular, and Small Lumpy Materials |
| Applicable Industries | Building Materials, Chemical, Coal, Grain & Oil, Feed, etc. |
| Conveyance Mode | Horizontal or Inclined |
| Ambient Temperature | -20 ~ 50 ℃ |
| Material Temperature | ≤ 200 ℃ |
| Characteristics | Not Suitable for Perishable, Sticky, or Agglomerated Materials |
| Driving Devices | Motor, Reducer, Coupling, or Drive Chain |
| Main Components | Screw Shaft (Main Shaft and Blade), Enclosed Housing, Cover Plate,
Feed Inlet, Sealing Plates at Both Ends, and Bearings |
| Advantages | Cost-effective, Efficient Material Distribution, Fully Enclosed
Dust-proof |
| Application Scenarios | Food Processing, Pharmaceuticals, Powder & Energy, Petrochemicals,
Chemicals, Mining & Minerals, Feed Processing, Plastics, etc. |
